Tiny Tapeout 8

Tiny Tapeout is an educational project that makes it easier and cheaper than ever to get your designs manufactured on a real chip! Instead of paying 10,000 dollars for taping out a chip, enthusiasts and hobbyists can submit designs and share the floorplans in the same chips, dramatically reducing the per-design cost for individuals.

The final chip product shipped to me will include a chip on a carrier board and a demo board to communicate with the chip.

Since I have completed ChipCraft‘s 8-bit calculator course (Slide 157 Lab ID: C-EQUALS), I decided to submit this design to the Tiny Tapeout 8th iteration (TT8), which is due on September 6, 2024.

Because my design is coded with TL-Verilog, I followed Steve Hoover‘s tt08-makerchip-template and the 5-minute YouTube tutorial, which are extremely helpful.

My submitted TT8 design can be found at ezchips/tt08-my-calc (github.com) repository.

During the process of compiling my design, I did run into GDS Build issue with the following error:

/home/runner/work/tt08-my-proj/tt08-my-proj/src/project.sv:124: ERROR: Identifier `\L1_Digit[0].L2_Leds[0].L2_viz_lit_a0' is implicitly declared and `default_nettype is set to none.

Steve provided me with a neat trick by adding `default_nettype wire to the first \SV region of the project.tlv file, and it worked beautifully.

Here is the snapshot of a successful submission reported by TT08’s discord group:

It is really cool to have a 2D and 3D view of my design’s floor plan in the chip, which includes many semiconductor components like gates, flip-flops, multiplexers, etc.

ChipCraft: Fibonacci and D Flip-Flop

The fibonacci sequence is a sequence of numbers where the first two terms are both 1 and the next terms are the sum of the two previous terms. In order to output the terms of this sequence using TL-Verilog, you need to be able to access previous cycles of numbers. This is where the “>>” operation comes in.

In TL-Verilog, >> indicates that you want the value of some previous cycle of a variable. The storage of values from previous cycle is realized through the “D Flip-Flop“, the square block with a small triangle in it. For example, if you set something equal to >>3$num, the value will be the value of num three cycles before. With this operation in mind, it seems fairly trivial to come up with the code for the fibonacci sequence. The line of code

$num[31:0] = >>1$num + >>2$num;

seems to be enough. What this line means is that the variable “num”s value is equal to the previous cycle’s value and the value two cycles earlier. However, the only issue with this is that for the first cycle, there is no previous cycle. The way to bypass this issue is through a reset variable and a multiplexer.

The reset variable has value 1 for the first couple cycles. Afterwards, the value becomes 0. This works well with a multiplexer, since you could define num as some value when reset is 1 and then start computing the rest of the terms when reset is 0. Since you want the first two terms to be 1, the lines of code will be the following:

$num[31:0] = $reset ? 1 : (>>1$num + >>2$num);

The waveform shows reset lasts more than two cycles (yellow highlighted), enough to get two previous cycles of consecutive “1” as the initial fibonacci sequence.

ChipCraft: Understand Pipelining

In order to get familiar with Makerchip platform and TL-Verilog, a pipelined Pythagorean example is given as a tutorial. The tutorial is very helpful, however, reading waveform can be a bit challenging especially when pipelining and the valid signal are combined together. Please read through the “VALIDITY TUTORIAL” from the “Tutorials” page.

Pipelining is an optimization strategy that involves executing parts of different tasks simultaneously. Imagine a program with three different sections. Each section takes the same amount of time to run. In the first cycle, the first part of the first task will receive its input and output it to the second part. In the second cycle, the second part of the first task will perform its job. However, the first part of the second task will also run at the same time. Then, in the third cycle, the third part of the first task will run and output the result. At the same time, the second part of the second task and the first part of the third task will also run. This allows the entire program to run much faster than iterating through each task individually.

The valid signal is composed of two random bits (for the Pythagorean example). This signal will determine if the program will run through a task with a ¼ chance of doing so. The picture below shows that when the valid signal is true (the line is green) the task runs and the numbers are highlighted. When it’s false (the line is blue) the numbers are grayed out.

However, you may be wondering why the numbers directly above the green line, unless there is a green line before it, are grayed out. This is because of the aforementioned pipelining strategy. The valid signal and the first part of the task aren’t run in the same section. The valid signal is determined first before being given to the first part. Because of this, the task that will actually run is the task in the cycle directly afterwards.

In the above waveform, I highlighted three tasks: task 1 (yellow), task 2 (red), and task 3 (blue). The solid yellow marks the valid cycle that is followed by pipeline 1 (@1) of task 1. The solid red marks the valid cycle that is followed by pipeline 1 of task 2. The solid blue marks the valid cycle that is followed by pipeline 1 of task 3. Note: the validity cycle only marks the initiating of pipeline 1 of a task and won’t prevent running of further pipelines for the same task even if the validity cycle is done.


ChipCraft – NAND Challenge

ChipCraft is a good course for beginners to learn chip design. I found it is compelling to break down some of its 300+ slides and hopefully it may help other newcomers with understanding the concepts when feeling confused with them.

Today I’ll show how I approached and solved the NAND Challenge.

We are given two circuits to make a NAND gate: the first one, default on, is only on when the current is zero and the second one, default off, is only on when the current is one. Both circuits have an input, an output, and a current. The current determines if the circuit will be on or off. If so, the input will be given to the output. Otherwise, the output is zero regardless of the value of the input.

In order to make a NAND gate, we need to make an AND gate and a NOT gate.

Build AND Gate

The AND gate’s truth table is:

Input A will be the current and input B will be the input for the circuit. Firstly, we need to determine which circuit to use. Since an AND gate only outputs 1 when both A and B are 1, we need the current to be 1 for the output to receive the input. Therefore, the circuit we will use is the default off circuit.

Note: We know that this is an AND gate because the truth table on the left is the truth table for a NAND gate and all four rows have an X.

Add NOT Gate

The NOT gate’s truth table is:

For this gate, we first need to determine whether the output for the AND gate should go to the current or the input of the circuit. If the current always remains the same, then the output will either always be 0 or whatever the input is, which is not what we want. Thus, the current will be given the output of the AND gate.

Next, we need to figure out what the input will be. If the input is always 0, then the output will always be 0 regardless of the current. Accordingly, the input will always be 1.

Finally, we will figure out what type of circuit we should use. When the current is 0, the circuit should return 1. Otherwise, it will return 0. From the above description of the circuits given in the first paragraph, we are positive that the circuit is the default on circuit.

Nature’s Strongest Force

In May 2024 issue of Scientific American, one of the articles in the magazine was “Nature’s Strongest Force” by Stanley J. Brodsky, Alexandre Deur, and Craig D. Roberts. The article talks about the recent accomplishment in measuring the strength of the strong force. The strong force is one of the four fundamental forces of nature. As the name suggests, the strong force is the strongest force in the universe. It is responsible for quarks being bonded together to form protons and neutrons. For a long time, physicists have had immense trouble in measuring the coupling constant of the strong force, denoted by αs (“alpha s”). This is because the αs grows exponentially as the distance between quarks increases. The region at which the strength is too great to measure is known as the Terra Damnata. However, when Deur measured αs at distances within the Terra Damnata, he found that at some point αs leveled out and became constant. Brodsky and de Teramond Peralta developed a method to measure αs at long distances and found that their calculations matched what Deur had computed. However, to say we definitively calculated alpha_s would require a quantum chromodynamics(QCD)-based equation. Two strategies emerged from the use of QCD equations: the “top-down” approach and the “bottom-up” approach. Roberts and Lei Chang computed results from the bottom-up approach and compared them with the results of the two leading physicists in the top-down approach. These four physicists found that both strategies were mutually compatible. Afterward, Roberts and other colleagues brainstormed and came up with a universal QCD equation. For the first time in history, we have data for αs at all distances.

Confused with 2’s Complement

While studying Udemy course “Digital Electronics & Logic Design Circuits” about 2’s complement and 1’s complement, I got puzzled with why all binary 1 (ex. 1111) is -1 in 2’complement, why positive 0 and negative 0 is same in 2’s complement, and why the range is different for 2’s and 1’s complements. I also had a misunderstanding that a negative number is the positive number with the most significant bit changed to 1, for example, -1 would be 1001.

Later, I learned the purpose of the complement system is mainly to perform subtraction through addition, for instance 7 – 2 is the same as 7 + (-2). It becomes straightforward by first listing positive numbers, and then listing individual negative numbers for 1’s and 2’s complements. I drew the following table with N=4 as an example and everything became clear.

It answers my questions:

  • Why 1111 is -1 in 2’s complement
  • Why 2’s complement solves the double zero issue
  • Why 1’s complement and 2’s complement have different ranges

Low-Cost, Low-Power, High-Capacity Quantum Simulation Device

This is a joint project by me and Ellen. It was inspired by a QxQ summer camp we both attended in 2023. Initially, it was aimed to develop a portable Quantum Computing simulator for educational purposes using the Jetson Orin Nano for its GPU acceleration, portability, and low power consumption (15-60w). We then discovered the Jetson Orin Nano’s efficiency in simulating more qubits compared to traditional GPUs (220-450w) like RTX3070, leading us to create a cost-effective, low-power quantum simulation device for researchers and faculty.

Memory Capacity Requirement for Qubits

In our research into the interplay between GPU capabilities and quantum simulators, we learned of a crucial relationship: a GPU’s internal memory size determines the maximum number of qubits it can simulate in a quantum computing scenario. This is governed by the equation for an N-qubit circuit:

Memory required (bytes) = 8 x 2N

Both the Jetson Orin Nano and the RTX3070, with their 8GB of GPU memory, can theoretically simulate up to 29 qubits. What’s remarkable is the vast difference in power consumption between the two: the Jetson Orin Nano uses a mere 7-15 watts compared to the RTX3070’s 220 watts, yet both can simulate an equal number of qubits.

Jetson Orin Nano (left) and RTX 3070 (right)

Jetson Orin’s Low Power High Qubit Capacity

Our findings, based on Nvidia’s documentation, are summarized in the table below:

GPU DeviceMemory Size (GB)Qubit CountsPower (w)Prices (USD)Power per Qubit (w)
Orin Nano829154990.52
AGX Orin64336019991.82
RTX 30708292205257.59
RTX 40902431450199914.52
RTX A6000483230048009.38
Power efficiency from various Nvidia’s GPU devices

This comparison highlights the Jetson Orin series’ capability to simulate a large number of qubits while consuming significantly less power than other high-end gaming or professional GPUs. It’s worth noting that the Orin devices are standalone computers, whereas other GPUs require installation in desktops or workstations, potentially increasing the overall power consumption and cost.

Comparison Test: Jetson Orin Nano vs RTX 3070

We are able to conduct a test to compare power consumption / qubit count for Jetson Orin Nano vs RTX 3070. We chose to install Qibo quantum simulator and ran the Grover models from its examples for both platform. Although both Jetson Orin Nano and RTX 3070 are equipped with 8G GPU memory and would theoretically be able to simulate up to 29 qubits, the Grover models can each only simulate 25 qubits. When we attempted to simulate 26 or more, program reports “Out of memory” error, indicating GPU memory is not sufficient.

We recorded temperature, power, memory usage, duration, and calculate total energy consumption for the run.

Jetson Orin NanoRTX 3070
Temperature (°C)5560
Power (Watts)6.1109
Memory (MB)41734257
Duration (Seconds)74094
Energy Cost (Watt-Seconds)451410246
Energy Cost per Qubit (Grover Algorithm with 25 qubits)181410

Based on the above test result we have concluded:

  • Energy Efficiency: The Jetson Orin Nano appears to be more energy-efficient in running the Grover Quantum Computing algorithm for 25 qubits. This is evident by the lower energy cost (watt-seconds) of 4514 for the Jetson Orin Nano, compared to 10246 for the RTX 3070.
  • Power Consumption: The RTX 3070 has a much higher power consumption rate at 109 watts versus the 6.1 watts of the Jetson Orin Nano. This is almost 18 times higher, which significantly contributes to the increased energy cost.
  • Performance Time: However, it’s essential to note that the RTX 3070 completes the task much faster, taking only 94 seconds compared to 740 seconds for the Jetson Orin Nano. This suggests that while the RTX 3070 is less energy-efficient, it performs the computation much more quickly.
  • Temperature: The RTX 3070 operates at a higher temperature (60°C compared to 55°C for the Jetson Orin Nano) which is consistent with its higher power usage.
  • Memory Usage: Memory usage is almost the same for both devices, with the RTX 3070 using slightly more memory (4257 MB) than the Jetson Orin Nano (4173 MB).
  • Energy Cost per Qubit: When it comes to the energy cost per qubit, the Jetson Orin Nano is more efficient at 181 watt-seconds per qubit, as opposed to the 410 watt-seconds per qubit of the RTX 3070.

From this comparison, we can infer that if energy consumption and cost are a concern, the Jetson Orin Nano is the more efficient option. However, if time performance is critical and power availability isn’t a limitation, the RTX 3070 may be the preferable choice despite its higher energy consumption. This could be relevant in scenarios where speed is more crucial than energy efficiency, such as time-sensitive computations or environments where energy cost is less of a factor.

Jetson AGX Orin Provides A Well Balance between Energy Cost and Computation Performance

While energy efficiency is very promising for Jetson Orin Nano, its lousy computation performance is of a concern. But here is the catch. Jetson Orin series has an extreme high performance variant, Jetson AGX Orin (see below), which provides a staggering 64G GPU memory with only 60w power consumption. We cannot afford one to examine its energy cost per qubit along with its computation performance, but it would be safe bet that AGX Orin likely would performance 10 times better than Orin Nano considering its much strong specifications.

Quantum On Edge: Is This A Real Thing?

One thing we didn’t mention much about the Jetson Orin is its tiny form factor compared to the traditional GPU card. In fact, the Jetson Orin itself is a computer whereas a traditional GPU card must be inserted into a bulky computer, resulting in even more energy efficiency with Jetson Orin series devices. Additionally, Jetson Orin is particularly aimed for portable IoT or Edge computing applications. While there is a qubit limitation (up to 33) for the Jetson Orin compared to the real quantum computer (hundreds and still evolving), there might be a place for small qubit count IoT applications, or shall we call it Quantum On Edge?

Loading MIT’s xv6 Operating System into Hardware

I learned a bit on the concept of Operating Systems (OS) in 2023 when I was still a middle schooler. To be honest, I don’t think I understood the whole concepts too well, but I got the basic ideas of the OS, which is that it is a software that acts as a bridge between program and hardware. For example, when users type something from a keyboard, move the cursor with the mouse, print something to the printer, or watch a video in the monitor, it is the OS that is actually translating the user’s requests and converts it to the operations that underlying hardware can understand.

I was wondering if there exists a piece of very simple OS software that I can to learn and understand how that process occurs. Luckily, I bumped into xv6, a simple Operating System that is used exactly for teaching students the concepts and leaving them to further expand on it.

It is very easy to launch through an emulator called QEMU, and provides some basic commands to run.

xv6 launched via QEMU

While I don’t have much knowledge of QEMU, I do know it is a platform that functions like a virtual machine (VM) hence the xv6 is running as a VM instead of directly on a real computer.

I was thinking that it would be fun to have xv6 run on a real piece of hardware or chips. Would that make a student better at understanding about how an OS interacts with the underlying hardware systems? Interestingly, someone already did it. Check out the following GitHub repository.

Port of xv6 to the Nezha RISC-V board using the Allwinner D1 SoC

It seems quite simple to get it running in the Allwinner D1 board with just a few runs of xfel commands. My understanding of xfel commands is to initialize the board memory, download xv6 OS image in the board, and then launch the OS. It requires a serial console to interact with the OS though.

xv6 launched in Allwinner D1 board

I’m going to use this little piece of hardware to learn the xv6. The little board is easy to get through Amazon. In fact, I found at least two boards from Amazon that are able to support xv6.

Sipeed RV Dock Allwinner D1 Single Board Computer

Sipeed Nezha 64bit RISC-V Linux SBC Board Allwinner D1

Note: The cable with Black/White/Green pins is the serial console cable, and the White USB-C cable is the data and power.

“We need a moonshot for computing” from MIT Technology Review

The article “We need a moonshot for computing” is basically saying that the United States needs to do something really big and bold to stay ahead in the computer chip game. It’s like when President Kennedy said he wanted to send a person to the moon. He set a huge goal for the whole country to work towards, and that’s what this article suggests the US needs to do now for computers.

There’s this thing called Moore’s Law that says computer chips get faster and cheaper over time because companies make the transistors (tiny switches) on them smaller and pack them closer together. But we’re reaching a point where they can’t get much smaller, which is a big problem because it means making chips faster and cheaper won’t work the same way anymore.

The US government passed a law called the CHIPS and Science Act, which is a plan to help build more chip factories in the US and to do more research to make better chips. They want to start this place called the National Semiconductor Technology Center, or NSTC, to gather lots of people educated on this field so that they can work together to invent new kinds of computer chips.

Cover Image of Chapter 13 “Microelectronics” from National Security Commission on AI

The article says we can keep improving chips a little bit at a time for the next 10 years, but after that, it’ll get extremely difficult. So, we should start thinking about totally new kinds of computers, such as ones that work like our brains or ones that use quantum mechanics to process information.

But all these new ideas are kind of risky because they’re different from what we’re used to, and nobody knows for sure if they’ll work out. The NSTC has to decide whether to play it safe and make small improvements or go all out and try for something as big as the moon landing but for computers.

In the end, the article is saying that now is a super important time for the US to figure out how to keep being the best at making computer stuff. If we don’t aim for something really huge and new, we might fall behind other countries.

Quantum Circuit Computation

For computation of quantum circuit I always try to use matrix calculations, which is quite tedious. Recently, I finally had a better understanding of tensor and got to know a much simpler way to compute the circuit. Take the following circuit as an example:

Where q0, q1, and q2 from top to bottom with q2 the MSB (most significant bit) and q0 the LSB (least significant bit). And the three-qubit state vector |ψ⟩ will be q2q1q0, with the MSB on the left.

The computation can be done by simply applying one of the followings to the individual qubit and then just expanding it.

Please note that the position of MSB matters, that means q2q1q0 and q0q1q2 are different. In this particular example, however, they are actually same, but this is just a coincidence. Whether the MSB is the leftmost or rightmost qubit is the individual’s choice as long as the same convention is consistent throughout the computation process. In this example I choose to put the MSB on the left to be consistent with the classical computer.
